4H3
Blackburn®* Actual product may vary from image
Type H High Strength Split-Bolt Connector, Bronze Alloy for Use on Copper Conductors, Conductor Range for Equal Main and Tap 4 Sol-8 Sol
Details
MFG PART #:4H3
TRC Part #:TBCO4H3
UPC #:783786200078
Inventory
$ C
Details
MFG PART #:4H3
TRC Part #:TBCO4H3
UPC #:783786200078
Inventory
Attributes
Features
Documentation
Attributes
Brand:Blackburn®
ETIM:EC000491
Type:Type H High Strength
Conductor Type:Solid Copper
Conductor Size:8 to 4 AWG
Bolt Size:17/32 x 1-9/32 in
Specifications:0.235 in Split, 23/32 in Hex Nut
Material:Bronze Alloy
Color:Metallic
Features
| Bolt and nut of high-strength corrosion resistant bronze alloy |
| Pressure bar is copper through 40H, copper alloy for 350 kcmil and above |
| Bolt and nut of hex design up to 350 kcmil |
| Split-bolt connector made of metallic bronze alloy for use on copper conductors |
| 16 AWG stranded conductor range min tap with one max main |
| 4 to 8 AWG solid conductor range for equal main and tap |
| Will accommodate three wires of maximum size |
| 100 Pieces/Pack |
