54942BE
Color-Keyed®* Actual product may vary from image
Copper One-Hole Lug, Long Barrel, Blind End, Max 35kV, Wire Size #2 AWG, 5/16 Inch Bolt Size, Tin Plated, Die Color Code Brown, Die Code 33
Details
MFG PART #:54942BE
TRC Part #:TBCO54942BE
UPC #:786210886350
Inventory
$ C
Details
MFG PART #:54942BE
TRC Part #:TBCO54942BE
UPC #:786210886350
Inventory
Attributes
Features
Documentation
Attributes
Brand:Color-Keyed®
Barrel Size:0.41 in Dia
Barrel Type:Blind End/Long
Color:Brown
Conductor Size:2 AWG
Conductor Type:Stranded Copper
Die Code:33
ETIM:EC001051
Material:Copper
Mounting Hole Size:0.344 in
Overall Length:2.03 in
Series:54900
Specifications:3/8 in Center of Hole to Tongue End, Tin Plated
Stud Size:5/16 in
Tongue Size:0.88 in L x 0.59 in W x 0.11 in THK
Tongue Type:Straight
Type:1-Hole Non-Insulated
Voltage Rating:600 V AC to 35 kV, 600 VAC to 35 kV
Features
| Connectors have colored bands or colored dots that correspond to color markings on the dies |
| Color-Keyed® connectors are banded by colored stripes or engraving to indicate location of die on connector for compression |
| Connection by compression |
| High quality connection at a low installed cost |
| High conductivity wrought copper construction |
| 3/8 in hole center to end |
| Tin plated finish |
