60548
Color-Keyed®* Actual product may vary from image
Two-Way Aluminum Splice Connector, Wire Size 4/0, Die Code 66, Die Color Code White
Details
MFG PART #:60548
TRC Part #:TBCO60548
UPC #:786210605487
Inventory
$ C
Details
MFG PART #:60548
TRC Part #:TBCO60548
UPC #:786210605487
Inventory
Attributes
Features
Documentation
Attributes
Brand:Color-Keyed®
ETIM:EC001059
Type:2-Way Standard Barrel
Conductor Type:Compact/Concentric/Stranded Aluminum/Copper
Conductor Size:4/0 AWG
Die Code:66
Voltage Rating:35 kV
Outside Diameter:0.86 in
Length:3.66 in
Specifications:Tin Plated
Temperature Rating:90 deg C
Material:Aluminum
Color Code:White
Features
| Manufactured from high conductivity wrought aluminum and electro tin plated |
| Connectors are pre-filled with oxide inhibitor |
| Permits aluminum conductors to be spliced to copper or aluminum conductors |
| For aluminum and copper concentric conductors and compact code aluminum strands |
| Suitable for use with TBM5, TBM5S, TBM6, TBM6S, TBM8, TBM8S tools |
| Connectors supplied with T&B® oxide inhibitor compound in wire bore |
