530P7W
LevitonĀ®* Actual product may vary from image
30 Amp, 277/480 Volt 3PY, IEC 309-1 & 309-2, 4P, 5W, North American-Rated Pin & Sleeve Plug, Industrial Grade, IP67, Watertight, - Red
Details
MFG PART #:530P7W
TRC Part #:LEVI530P7W
UPC #:078477838266
Inventory
$Ā E
Details
MFG PART #:530P7W
TRC Part #:LEVI530P7W
UPC #:078477838266
Inventory
Attributes
Features
Documentation
Attributes
Brand:LevitonĀ®
Amperage Rating:30 A
Color:Red
Dimensions:3.98 in Dia x 7.4 in L
Enclosure:IP67
Frequency Rating:50/60 Hz
Grade:Industrial
Material:ValoxĀ® 357
Number of Poles:4
Number of Wires:5
Series:Series II
Temperature Rating:-40 to 60 deg C
Terminal Type:Screw
Type:Watertight
Voltage Rating:277/480 V AC, 277/480 VAC
Features
| Rugged housing, made of superior performance PBT, provides maximum corrosion protection and makes the device more resistant to impact, abuse and temperature extremes and V-0 flame rated and superior UV stability |
| Solid brass pins |
| Reinforced nylon contact carrier |
| Certified for current interrupting at full rated current |
