RA2573

Sta-KonĀ®

* Actual product may vary from image

Nylon Fully Insulated Female Disconnect, Length 1.01 Inches, Width .38 Inches, Maximum Insulation .165, Tab Size .250x.032, Wire Range #22-#18 AWG, Color Red, Brass, Tin Plated, 1,000 Pack

Details

MFG PART #:RA2573

TRC Part #:TBCORA2573

UPC #:786210856698

Inventory

$Ā C
**Must be ordered in quantities of 1000**

Details

MFG PART #:RA2573

TRC Part #:TBCORA2573

UPC #:786210856698

Inventory

Attributes

Brand:Sta-KonĀ®
Barrel Type:Brazed Seam
Color:Red
Conductor Size:22 to 18 AWG
Dimensions:1.01 in L x 0.38 in W
ETIM:EC000516
Finish:Electroplated Tin
Insulated:Fully Insulated
Material:Brass
Series:250
Specifications:0.165 in Dia Maximum Insulation, 0.03 in THK Stock
Tab Size:0.25 in W x 0.032 in THK
Temperature Rating:105 deg C
Terminal Type:Crimp
Voltage Rating:600 V AC, 600 VAC
