RC10-38X
Sta-KonĀ®* Actual product may vary from image
Nylon Insulated Expanded Entry Ring Terminal, Length 1.38 Inches, Width .59 Inches, Maximum Insulation .250, Bolt Hole 3/8 Inch, Wire Range #12-#10 AWG, Color Yellow, Copper, Tin Plated
Details
MFG PART #:RC10-38X
TRC Part #:TBCORC1038X
UPC #:786210804460
Inventory
$Ā C
Details
MFG PART #:RC10-38X
TRC Part #:TBCORC1038X
UPC #:786210804460
Inventory
Attributes
Features
Documentation
Attributes
Brand:Sta-KonĀ®
Barrel Type:Insulation Grip Sleeve
Color:Yellow
Conductor Size:12 to 10 AWG
ETIM:EC001052
Finish:TiN Coated
Length:1.38 in
Material:Copper
Series:RC Series
Specifications:1/4 in Dia Maximum Insulation, 0.48 in Clearance, Nylon Insulation
Stud Size:3/8 in
Temperature Rating:105 deg C
Tongue Size:0.59 in W x 0.04 in THK
Tongue Type:Ring
Type:Expanded Insulated
Voltage Rating:600 V AC, 600 VAC
Features
| Suffix X indicate an expanded insulation grip, means a wider wire entry to accommodate heavy wall insulation, nylon insulated, Self-insulated with high dielectric strength nylon sleeves |
| An inner bronze insulation grip sleeve lengthens the flexing radius of the conductor and eliminates conductor creep |
| Made of copper and has electro-tin plating for high conductivity/corrosion resistance |
| Expanded entry |
| 50 pieces/pack |
